Description

Applications:

Concrete Cutting: It excels in cutting concrete structures such as walls, floors, and pillars.
Demolition: Useful in controlled demolition where sections of concrete need to be removed without causing excessive vibration or damage.
Construction: Used for creating openings in concrete structures, such as for doors, windows, or utility passages.

Technical Specification

TECHNICAL SPECIFICATION
Voltage	3-PHASE ( 380V )
Rated input power ( Main motor / walking motor )	22 Kw / 0.2 Kw
Speed	980 RPM
Wire speed / walking motor speed	0-40 M/sec / 0-144 M/sec
Pulley size ( Main drive pulley / support pulley )	500mm / 200mm
Average cutting efficiency with moderate steel	(5m² / Hr )
Size	2400900900mm ( Track length 1.5 Mtr )
Weight	375kg
features	Fully automatic , forward reverse of main shaft and main motor walking , fully workable by wireless remote
