| ENGINE |
|
| Power source |
Corded |
| MOTOR |
|
| Rated input power |
2.7 kW |
| Frequency |
50-60 Hz |
| Phases |
1 ph |
| CUTTING EQUIPMENT |
|
| Cutting depth, max |
125 mm |
| Blade diameter, max |
350 mm |
| Arbor diameter |
25.4 mm |
| Blade thickness, max |
5.6 mm |
| Peripheral speed, max |
100 m/s |
| Coolant |
Wet /dry |
| DIMENSIONS |
|
| Product size length |
631 mm |
| Product size width |
221 mm |
| Product size height |
313 mm |
| Weight (complete product w/o side packed articles) |
7.6 kg |
| SOUND AND NOISE |
|
| Sound power level, guaranteed (LWA) |
105 dB(A) |
| Sound pressure level at operators ear |
95 dB(A) |
| VIBRATION |
|
| Vibrations left/front handle |
3.5 m/s² |
| Vibrations right/rear handle |
3.5 m/s² |
| CERTIFICATIONS |
|
| Cert machine dir. 2006/42/EC Decl. No. |
CB SE-89319 |
