Performance data
|
| Impact rate at rated speed |
1,380 – 2,760 bpm |
| Rated speed |
150 – 305 rpm |
Additional data
|
| Rated input power |
1500 W |
| Impact energy (according to EPTA 05/2016) |
12.5 J |
| Weight |
8.9 kg |
| Tool holder |
SDS max |
Drilling range
|
| Drilling dia. concrete, hammer drill bits |
12 – 45 mm |
| Opt. appl. range concrete, hammer drill bits |
20 – 40 mm |
| Drilling dia. concrete, breakthrough drill bits |
80 mm |
| Drilling diameter in concrete with core cutters |
125 mm |
Total vibration values (Hammer drilling in concrete)
|
| Vibration emission value ah |
8 m/s² |
| Uncertainty K |
1.5 m/s² |
Total vibration values (Chiselling in concrete)
|
| Vibration emission value ah |
7 m/s² |
| Uncertainty K |
1.5 m/s² |
Hammer drilling in concrete
|
| Vibration emission value ah |
8 m/s² |
| Uncertainty K |
1.5 m/s² |
Chiselling in concrete
|
| Vibration emission value ah |
7 m/s² |
| Uncertainty K |
1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level dB(A); Sound power level dB(A). Uncertainty K= dB.
